Component Type (ETIM Class)
Power switching circuit breaker
Electrical
Rated current In: 10 A
Number of poles: 3
Max. rated operation voltage Ue AC: 525 V
Rated ultimate short-circuit breaking capacity lcu at 415 V, 50 Hz: 85 kA
Rated service short-circuit breaking capacity lcs at 400 V, 50 Hz: 85 kA
Type of protection trip unit: Thermal/magnetic release
Trip curve: Fixed thermal, fixed magnetic
Frame size rating: 30 A
Rated frequency: 50-60 Hz
Rated insulation voltage Ui: 690 V
Rated impulse withstand voltage Uimp: 8 kV
AC power loss per pole at In: 5.66 W
Electrical life at Un, In (service cycles): 10000 cycles
