Serial: 19445
Rated current In160 A
Number of poles 4
Max. rated operation voltage Ue AC 525 V
Rated ultimate short-circuit breaking capacity lcu at 415 V, 50 Hz65 kA
Rated service short-circuit breaking capacity lcs at 415 V, 50 Hz36 kA
Type of protection trip unit Earth leakage circuit breaker
Trip curve Adj. thermal, fixed magnetic
Frame size rating250 A
Long time overload protection adjustment range100-160 A
Integrated earth fault protection Yes
Rated frequency50-60 Hz
Rated insulation voltage Ui525 V
Suitable for isolation Yes
Rated impulse withstand voltage Uimp8 kV
Reverse connection of supply possible Yes
AC power loss per pole at In13.33 W
Electrical life at Un, In (service cycles)10000 cycles
