Category
|
||
|
Mfr
|
|
|
|
Series
|
|
|
|
Packaging
|
|
|
|
Part Status
|
Active
|
|
|
Mounting Type
|
||
|
Coil Voltage
|
|
|
|
Contact Form
|
DPDT (2 Form C)
|
|
|
Contact Rating (Current)
|
15 A
|
|
|
Switching Voltage
|
120VAC - Nom
|
|
|
Load - Max Switching
|
-
|
|
|
Coil Current
|
11 mA
|
|
|
Coil Type
|
Non Latching
|
|
|
Features
|
-
|
|
|
Termination Style
|
Plug In, Quick Connect - 0.187" (4.7mm)
|
|
|
Seal Rating
|
-
|
|
|
Coil Insulation
|
Class B
|
|
|
Must Operate Voltage
|
102 VAC
|
|
|
Must Release Voltage
|
12 VAC
|
|
|
Operate Time
|
13 ms
|
|
|
Release Time
|
10 ms
|
|
|
Operating Temperature
|
-45°C ~ 70°C
|
|
|
Contact Material
|
Silver Cadmium Oxide (AgCdO)
|
|
|
Approval Agency
|
CSA, UR
|
