KEV
1 - 316SS
F - 0-100psig
F - 100psig (6.8 bar)
A - Side Mount
3 - = 1/8 in. female NPT inlet; 1/4 in. female NPT outlet(s)
2 - PEEK
1 - 0.02
A - = Alloy X-750 diaphragm (outlet pressures up to 500 psig [34.4 bar])
W - = Antitamper nut, side mount
0 - No Valve
0 - No Connections
0 - No Gauges
9 - 200W
| Maximum Inlet Pressure | 3600 psig (248 bar) |
| Pressure Control Ranges | 0 to 10 psig (0.68 bar) through 0 to 3600 psig (248 bar) |
| Flow Coefficient | 0.02 or 0.06 |
| Electrical | Supply: 120 and 240 V (ac) (± 10 %), 50/60 Hz Heater Ratings: 50, 100, 150, and 200 W |
| Control Temperature Ranges | 75 to 380°F (23 to 193°C) |
| Explosive Atmosphere / Hazardous Location Certification |
|
