Number of normally open contacts as main contact: 3
Number of normally closed contacts as main contact: 0
Rated operation current Ie at AC-3, 400 V: 72 A
Rated operation power at AC-3, 400 V: 40 kW
Rated operation current Ie at AC-1, 400 V: 100 A
Max. rated operation voltage Ue AC: 690 V
Voltage type for actuating: AC
Control supply voltage Us at AC 50HZ: 240 V
Number of auxiliary contacts as normally open contact: 0
Number of auxiliary contacts as normally closed contact: 0
Rated operation current Ie at AC-3, 690 V: 42 A
Rated operation power at AC-3, 690 V: 40 kW
Rated operation power at AC-4, 400 V: 15 kW
Control supply voltage Us at AC 60HZ: 277 V
Power consumption, AC coil pickup: 235 VA
Power consumption, AC coil hold-in :19.6 VA
Type of electrical connection of main circuit: Screw connection
Rated operation current Ie at AC-4, 400 V: 31 A
