SMC
SMC VHS40-N04A Manual 3-Port Residual-Pressure Relief Valve
- SKU
- P-SM-S-4808
$50.00
Price includes GST.
Low stock: 2 left
Warehouse pickup available
- Weight
- 1.0 kg
Specifications
| Manufacturer | SMC |
|---|---|
| Product type | PNEUMATICS |
| SKU | P-SM-S-4808 |
| Weight | 1.0 kg |
Description
SMC VHS40-N04A manually actuated, modular three-port residual-pressure relief valve, VHS single series, body size 40, with locking holes as recorded in the source title.
- Flow direction: left to right.
- Handle colour: white.
- Recorded pressure range: 1–10bar / 15–145psi.
- Connections: two 1/2-inch NPT female pneumatic threaded ports, as recorded; exhaust-port details are not supplied.
- Body: die-cast aluminium.
- Bonnet and handle: source-described flame-resistant PBT.
- Ambient operating temperature: -5 to +60°C.
This is a manually operated air-preparation valve, not an automatically certified overpressure safety device. Confirm port arrangement and installation requirements; no lock is listed as included.
