| Product attributes | |
|---|---|
| Connection diagram | ISO 4401-03-02-0-05 |
| Product family | WH,P.6 |
| Operating pressure, max. [bar] | 315.0 |
| Max. flow [l/min] | 60.0 |
| Spool symbol | Symbol D |
| Type of connection | Subplate mounting |
| Size | 6 |
| Type of actuation | with hydraulic actuation |
| Number of ports | 4 |
| Number of switching positions | 2 |
| Electrical connection description | Connector 3-pole (2 + PE) according to EN 175301-803 |
| Hydraulic fluid | HFC HL HLP HLPD HVLP HVLPD |
| Seals | NBR |
