| Product Type | Power Relay | |
|
|
Coil Voltage | 24 V dc |
|
|
Contact Configuration | 4PDT |
|
|
Series | LY4N |
|
|
Terminal Type | PCB Pin |
|
|
Switching Current | 10 A |
|
|
Switching AC Voltage | 125 V ac |
|
|
Switching DC Voltage | 125 V dc |
|
|
Switching Power | 2.5W |
|
|
Minimum Operating Temperature | -25°C |
|
|
Coil Resistance | 350Ω |
|
|
Maximum Operating Temperature | 55°C |
|
|
Standards/Approvals | CSA, UL |
|
|
Width | 36 mm |
|
|
Height | 28mm |
|
|
Coil Power | 1.5W |
|
|
Length | 41.5mm |
|
|
Contact Material | Silver Alloy |
|
|
Contact Resistance | 50mΩ |
