OEX
DXS9141 OEX 24V, 12TH Starter Motor, CW Delco Style for Caterpillar (6405N-WB)
- SKU
- P-OE-O-8572
$420.00
Price includes GST.
Low stock: 1 left
Warehouse pickup available
- Weight
- 19.0 kg
Specifications
| Manufacturer | OEX |
|---|---|
| Product type | AUTOMOTIVE & TRUCK PARTS |
| SKU | P-OE-O-8572 |
| Weight | 19.0 kg |
Description
| Part No. | DXS9141 |
| Type | STARTER MOTOR |
| Brand | OEX |
| Unit of Measure | EACH |
| Description | STR 24V 12TH CW DELCO 37MT STYLE |
| Warranty | 3yr Passenger 1yr Commercial |
| Flange Diameter | 89mm |
| Mount Centres A | 127mm |
| Mount Centres B | 90mm |
| Mount Centres C | 90mm |
| Mount Hole Diameter | 11 |
| Number of Teeth | 12 |
| Overall Length | 400mm |
| Pinion at Rest | 48mm |
| Pinion Diameter | 46mm |
| Power Rating | 4.5kW |
| Rotation | CW |
| Series | 37MT |
| Suits Unit Make | Delco |
| Voltage | 24 |
| Note | 37MT. Length may vary. |
| Weight | 22.997kg |
| Item Type | Starter Motor |
| New / Reman. | New |
| Starter Mount Type | 3 Hole |
| Wet / Dry Clutch | Wet or Dry |
| Product Group 1 | ROTATING ELECTRICAL |
| Product Group 2 | STARTER MOTORS |
