Embelton NR2 Anti-Vibration Mount – White 70kg M10

Embelton NR2 white anti-vibration isolation mount. The source identifies a rubber, single-deflection mount with an M10 fastening reference.

Recorded NR2 details

• Maximum load: 70 kg
• Static deflection: 6 mm
• Dimensions/reference as supplied: 76 mm × 32 mm × M10; the two dimension axes are not labelled

Source range information

The source describes noise and vibration isolation for equipment operating at 1,000 RPM upwards, including pumps and fans, generator sets, general industrial and mobile equipment, electrical transformers and packaged air conditioning equipment.

Its NR/NRD range notes describe a top threaded insert, a rated static-deflection range of 5–10 mm, a non-skid ribbed base, colour-coded load identification and a corrosion-resistant elastomer element with embedded metal parts. The range note says bolting down is not normally required; confirm mounting restraints for your installation rather than relying on that as a universal instruction.

Select the mount for the actual supported load, equipment speed and installation. The specific NR2 deflection above is 6 mm, not the full range value for every application.
