| SOCKET-OUTLET | INLET | |
| RATED CURRENT (A) | 30 | 30 |
| PHASING | 3P+N+E | 3P+N+E |
| MIN. RATED VOLTAGE (V) | 220 | 380 |
| MAX. RATED VOLTAGE (V) | 440 | 440 |
| IP RATING | IP55 | IP54 |
| RATED VOLTAGE (V) | 440 | 440 |
| FREQUENCY | AC | AC |
| MARKING | CE | CE |
| MATERIAL | POLY | POLY |
| PRODUCT COLOUR | BLUE | BLUE |
| IK | IK09 | IK09 |
| MIN. OPERATING TEMPERATURE (°C) | -40 | -40 |
| MAX. OPERATING TEMPERATURE (°C) | +60 | +60 |
| MIN. FLEXIBLE CONDUCTOR | 2,5MM2 | 2,5MM2 |
| MAX. FLEXIBLE CONDUCTOR | 6MM2 | 6MM2 |
| MIN. STRANDED CONDUCTOR | 2,5MM2 | 2,5MM2 |
| MAX. STRANDED CONDUCTOR | 10MM2 | 10MM2 |
| TYPE OF CONNECTION | TO SCREW | TO SCREW |
| N° OF KEYING POSITION | 24 | 24 |
| NOTCHES | 01 | 01 |
| COLOUR-CODED RING | RED | RED |
