LINCOLN
Lincoln 85732 FlowMaster II Hydraulic Grease Pump — Pump Only
- SKU
- P-LI-L-8104
- Weight
- 20.0 kg
Specifications
| Manufacturer | LINCOLN |
|---|---|
| Product type | PUMP |
| SKU | P-LI-L-8104 |
| Weight | 20.0 kg |
Description
Lincoln 85732 FlowMaster II hydraulically operated grease pump, also recorded as 01-085732, with source-described adjustable flow and pressure control.
Pump only. The existing listing states Reservoir Size: 27kg/60lb. This is retained as the stated application size, not a claim that a reservoir, bucket, follower or vent valve is included.
Original FlowMaster technical data — configuration ranges
The source table includes several reservoir sizes, dip-tube lengths and assembly configurations. Confirm which figures apply to this exact 85732 / 01-085732 pump, including fitted manifold/solenoid components, before selecting it.
| Function principle | hydraulically operated piston pump | |
| Outlets | 1 | |
| Metering quantity adjustable | 115-737 cm³/ min | 7-45 in³/ min |
| Lubricant | grease NLGI 0, 1, 2 | |
| Operating temperature | –29 to +65 °C | –20 to +150 °F |
| Hydraulic fluid temperature | max. +93 °C | max. +200 °F |
| Operating inlet pressure | 20-32 bar | 300-420 psi |
| Supply inlet pressure | max. 200 bar | max. 3000 psi |
| Reservoir capacity | 16; 27; 41; 54; 180 kg | 35; 60; 90; 120; 400 lb |
| Material | fluoroelastomer, polyurethane, steel, aluminum zinc casting | |
| Connection outlet | 1/4 NPTF | |
| Solenoid valve coil | 24 V DC | |
| Hydraulic inlet port | SAE 4 | |
| Tank return port | SAE 6 | |
| Hydraulic inlet flow | max. 28 l/min | max. 7 gal/min |
| Operating voltage | 24 V DC | |
| Transmission ratio with manifold | ||
| at low inlet pressure (20-25 bar, 300-350 psi) and flow (below 7 lpm, 2 gpm) | 9:1 | |
| at higher inlet pressure and flow | 11:1 | |
| Dimensions | ||
| Pump, dip tube length | min. 348 mm max. 864 mm |
min. 13.7 in max. 34.02 in |
| Basic pump | min. 610 × 231 × 291 mm max. 1126 × 231 × 291 mm |
min.24 × 9 × 11.5 in max. 44.3 × 9 × 11.5 in |
| Pumps with bucket, follower and vent valve | min. 633 × 496 mm max. 1 155 × 496 mm |
min. 24.9 × 19.5 in max. 45.44 × 19.5 in |
| Mounting position | vertical | |
The source inlet-pressure entries 20-32 bar and 300-420 psi are not precisely equivalent; confirm the required operating limits from the exact configuration documentation. The 24 V DC entries relate to the listed controls; the pump is described as hydraulically operated, not as an electric-drive pump.
Existing catalogue context includes Hitachi and SKF. Match the exact pump reference and lubrication-system arrangement before ordering.
