| Model Type | 830E-16, 830E-15, 830E-14, 830E-13, 830E-12, 930E-4, 730E-5, 830E-1, 730E-4, 930E-3, 930E-2, 930E-1, 930E, 830E, HD1500-5 |
|---|
Specifications
- Temperature range from -40 to 250°F
- Pressure connection: 1/4″-18 and 1/8″-27 NPT, 9/16″-18 UNJF-3A
- At 28 VDC:
- 7 amps resistive
- 4 amps inductive
- 2 1/2 amps lamp load
- 303 stainless steel hydraulic module housing
- Polyphenylene sulfide electric module housing
- Lead wire connectors
- Single pole single throw
- Single pole double throw
- Nitrile “o”-ring, fluorocarbon and ethylene propylene
- UL Listed
- NEMA Type 4 rating
- Integral pressure port snubbing
