| Output function | normally open / normally closed; (selectable) |
| Sensing range[mm] | 20 |
| Housing | cylindrical |
| Dimensions[mm] |
Ø 34 / L = 98 |
| Operating voltage[V] | 20...250 AC/DC |
| Protection class | II |
| Reverse polarity protection | no |
| Output function | normally open / normally closed; (selectable) |
| Max. voltage drop switching output DC[V] | 6 |
| Max. voltage drop switching output AC[V] | 6.5 |
| Minimum load current[mA] | 5 |
| Max. leakage current[mA] | 2.5 (250 V AC) / 1.3 (110 V AC) / 0.8 (24 V DC) |
| Permanent current rating of switching output AC [mA] | 250; (350 (...50 °C)) |
| Permanent current rating of switching output DC [mA] | 100 |
| Short-time current rating of switching output[mA] | 2200; (20 ms / 0,5 Hz) |
| Switching frequency AC[Hz] | 25 |
| Switching frequency DC[Hz] | 50 |
| Short-circuit proof | no |
| Overload protection | no |
