IFM
ifm EVT362 M12 Socket Connecting Cable, 10 m PVC
- SKU
- P-IF-I-3962
$45.00
Price includes GST.
Low stock: 2 left
Warehouse pickup available
- Weight
- 2.0 kg
Specifications
| Manufacturer | IFM |
|---|---|
| Product type | DATA & COMMUNICATION |
| SKU | P-IF-I-3962 |
| Weight | 2.0 kg |
Description
10m PVC Cable with M12 Connector
- For use in hygienic and wet areas in the food industry
- Permanent, reliable sealing even when mounted without tools
- Large operating temperature range and high protection rating
- Vibration and shock resistant thanks to coupling ring with locking mechanism
- LEDs clearly visible even under bright lighting
| Operating voltage[V] | < 250 AC / < 300 DC |
| Protection class | II |
| Max. current load total[A] | 4 |
Operating conditions
| Ambient temperature[°C] | -25...100 | |
| Note on ambient temperature |
|
|
| Ambient temperature (moving)[°C] | 5...100 | |
| Note on ambient temperature (moving) |
|
|
| Storage temperature[°C] | -25...55 | |
| Storage humidity[%] | 10...100 | |
| Other climatic conditions for storage according to stated class |
|
|
| Protection | IP 65; IP 67; IP 68; IP 69K |
