HANYOUNG NUX
Hanyoung Nux DX7_PMWNR Digital Temperature Controller, PT100
- SKU
- P-HA-H-2911
$250.00
Price includes GST.
Low stock: 1 left
Warehouse pickup available
- Weight
- 1.5 kg
Specifications
| Manufacturer | HANYOUNG NUX |
|---|---|
| Product type | ELECTRICAL |
| SKU | P-HA-H-2911 |
| Weight | 1.5 kg |
Description
Dimensions: 72 mm × 72 mm front panel size
Temperature Range: -199 °C to 640 °C (depending on sensor configuration)
Input Type: RTD (PT 100) input support
Main Output Options:
- Relay Contact Output (5A N.O. / 3A N.C. at 250V AC resistive)
- Current Output (4–20 mA DC)
- Solid State Relay (SSR) / Pulse Output (12V DC)
Alarm Output: High and low alarm outputs (5A N.O.)
Control Features: PID auto-tuning, direct/reverse action selection, Control Loop Break Alarm (LBA), and decimal point/limit settings.
Power Supply: 100–240V AC (50/60 Hz)
- Select direct action / reverse action internally
- High and Low alarm output
- Control Loop Breaks Alarm (LBA)
- Decimal point display and high / low setting limitation
- Retransmission output
