Replaced by: CDA240T
| Rated fault current | 30 A |
|---|---|
| Leakage current type | A |
| Frequency | 50 |
| Width in number of modular spacings | 2 |
| Rated current | 40 A |
| Connectable conductor cross section multi-wired | 1 mm² |
| Connectable conductor cross section solid-core | 1 mm² |
| Short-circuit breaking capacity (Icw) | 6 kA |
| Number of poles | 2 |
| Pollution degree | 2 |
| Short-time delayed tripping | No |
| Degree of protection (IP) | IP20 |
|---|---|
| Rated impulse withstand voltage Uimp | 4 kV |
| Built-in depth | 70 mm |
| Rated voltage | 240 V |
| Surge current capacity | 0.25 kA |
| Additional equipment possible | Yes |
| With interlocking device | Yes |
| Selective protection | No |
| Ambient temperature during operating | -25 °C |
| Rated insulation voltage Ui | 500 V |
| Mounting method | DIN rail |
