In line medium pressure filter assembly with cleanable or disposable elements
Max flow rate: 400 l/min
Max working pressure: 160 Bar (2320 psi)
Test pressure: As per NFPA T 3.10.5.1. 240 Bar (3480)
Burst pressure: As per NFPA T 3.10.5.1: 480 Bar (6962 psi)
Connection Ports: BSP, NPT
By-pass: No By-pass or 6 Bar (87 psi) setting
Working temperature: -25C + 120C
Materials: Head: Cast iron
Bowl: Aluminum
Seal Buna-N / Viton
Filter Element
Filter media: Microglass fiber 3,6,10,15,25 u, cellulose 10u
Collapse pressure: As per ISO 2941: 21 Bar (305 psi) and 210 Bar (3045 psi)
| INTERNORMEN | 01NL25025VG30EP |
| INTERNORMEN | 01NL25025VG30EV |
| INTERNORMEN | 301899 |
| INTERNORMEN | 301900 |
| STAUFF | NL250E25B |
| FILTRATION GROUP | PI25025DN |
| EPPENSTEINER | 20250H20SLA000P |
| EPPENSTEINER | 20250H20XLA000P |
| REXROTH | 20250H20XLA000M |
| REXROTH | 20250H20XLA000V |
| REXROTH | 20250H20XLA000M |
| REXROTH | 20250H20XLA000V |
| REXROTH | R928006864 |
| REXROTH | R928006891 |
| MAIN FILTER | MF0436082 |
| HY-PRO | HP52NL1025MV |
| HY-PRO | HP52NL1025MB |
| NATIONAL FILTERS | PEP204001025GV |
| REXROTH | 20250PWR20A000M |
| REXROTH | 20250PWR20A000V |
| INTERNORMEN | 01NL25025VG30S1P |
| INTERNORMEN | 01NL25025VG30S1V |
| INTERNORMEN | 01NL25025VG30S1P |
| INTERNORMEN | 01NL25025VG30S1V |
| HY-PRO | HP32NL1025MB |
| HY-PRO | HP32NL1025MV |
| HYDAC | 0250DN025BN3HC |
| HYDAC | 0250DN025BNHC |
| HYDAC | 319489 |
| HYDAC | 0250DN025BN4HC |
| PARKER | G04116 |
