- Mounting position optional
- Conforms to standard ISO 5599-1
- Operating medium Compressed air to ISO 8573-1:2010 [7:-:-]
- Note on operating and pilot medium Ester oil < 0.1 mg/m³, to ISO 8573-1:2010 [-:-:2]
- LABS (PWIS) conformity VDMA24364-B2-L
- Storage temperature -20 °C ... 80 °C
- Media temperature -10 °C ... 60 °C
- Ambient temperature -10 °C ... 60 °C
- Product weight 320 g
- Mounting method for sub-base With through-hole
- Type of mounting With through-hole
- Pilot air port 12/14 G1/8
- Auxiliary pilot air port 12 G1/8
- Auxiliary pilot air port 14 G1/8
- Pilot air port 12 G1/8
- Pilot air port 14 G1/8
- Pneumatic connection, port 1 G1/4
- Pneumatic connection, port 2 G1/4
- Pneumatic connection, port 4 G1/4
- Material sub-base Die-cast aluminum
