Rated voltage AC UL
700 V
Rated voltage AC IEC
690 V
Rated current
800 A
ROHS Compliant
Yes
AC or DC
AC
Speed/Characteristic
aR
Fuse size
32
Mounting
Bolted
Clearing I2t At Rated Voltage
660 kA²s
Melting I2t
115 kA²s
AC Max I.R./Breaking Capacity: I1
200 kA
Power Dissipation at Rated Current Value
110 W
Design Details
Standard Terminal
Indication System
Yes
Indication System Type
Striker
Contact materials
Silver-Plated Brass
Connection/Terminal Type
End Contact with Threaded Holes
Body/Insulating Material
Ceramic
Product Weight
0.5463 kg
Product Width
59 mm
Product Length
50.6 mm
Product Height
65 mm
