EUCHNER
EUCHNER EGT12ASFM5 Limit Switch
- SKU
- P-EU-E-3816
$200.00
Price includes GST.
Low stock: 1 left
Warehouse pickup available
- Weight
- 1.0 kg
Specifications
| Manufacturer | EUCHNER |
|---|---|
| Product type | Electrical |
| SKU | P-EU-E-3816 |
| Weight | 1.0 kg |
Description
- Rated insulation voltage Ui: 50 V
- Switching current (min. at 24 V ): 1 mA
- Switching voltage (min.): 1 V
- Utilization category: AC-12 0.3A 30V, DC-13 0.3A 24V
- Actuating element: Ball plunger
- Actuating force: approx. 16 N
- Approach speed: 0.01 - 8 m/min
- Cable ambient temperature (static): -25 - +80 °C
- Connection: Plug connector M12
- Degree of protection: IP67
- Design: Thread M12 x 1
- Installation orientation: any
- Material: Threaded section: stainless steel, Contact: Rhodium, Sleeve: Brass, nickel plated
- Mechanical life: 30 x 10⁶
- Number of NO contacts: 1
- Repeat accuracy (absolute): ±0.01 mm
- Switching principle: Reed contact
