| Pilot Pressure | 1 |
13.5 (PVE)
|
| Voltage | 4 |
24
|
| Connector Type | 2 |
1x4 AMP JPT SAAB
|
| Connector Direction | U |
90 (Up)
|
| Control Signal | O |
On/Off
|
| CAN Protocol | 0 |
N/A
|
| Digital Type | 0 |
N/A
|
| Float Direction | 0 |
N/A
|
| Hysteresis | 0 |
N/A
|
| On-Stroke Response A | B |
225 ms
|
| On-Stroke Response B | B |
225 ms
|
| De-Stroke Reaction A | 9 |
90 ms
|
| De-Stroke Reaction B | 9 |
90 ms
|
| Resolution | 0 |
N/A
|
| Max Oil Consumption | 0 |
0 l/min
|
| Max Oil Consump. Steady State | 0 |
0 l/min
|
| Fault Reaction & Recovery | 0 |
N/A
|
| Output Signal | 0 |
N/A
|
| Disable Function | 0 |
N/A
|
| Nominal A Stroke | 7 |
7
|
| Nominal B Stroke | 7 |
7
|
| Minimum Float Position | 0 |
N/A
|
| IP Rating | 6 |
IP66
|
| Manual Override | 0 |
N/A
|
| Coil Power | 8 |
8 W
|
| Port Connection Type | 0 |
N/A
|
| A Port Placement | 0 |
N/A
|
| B Port Placement | 0 |
N/A
|
| Extra Function | 0 |
N/A
|
| Valve Side Interface | 0E |
PVE32 O-Ring
|
| Outward Side Interface | 00 |
N/A
|
| Length | 106 |
106
|
| Pilot Pressure Neutral | 0 |
N/A
|
| Pilot Pressure Full Stroke | 0 |
N/A
|
| Maximum System Pressure Peaks | C |
60
|
| Primer | 0 |
N/A
|
| Product Category | 5 |
Obsolete
|
| Marking | E |
CE
|
| Ex Application | 0 |
N/A
|
| Certification | CS |
ISO13849 Compliant
|
| PVDI connector coding | 0 |
N/A
|
| Marking | E |
CE
|
| Port Size | 00 |
N/A
|
| Product type |
N/A
|
|
| Voltage | 4 |
24
|
