CABAC
Cabac XLP25RD/4FT Red Heatshrink Tube 25.4 mm – Bag of 5
- SKU
- P-CA-C-8827
$30.00
Price includes GST.
Low stock: 1 left
Warehouse pickup available
- Weight
- 2.5 kg
Specifications
| Manufacturer | CABAC |
|---|---|
| Product type | ELECTRICAL |
| SKU | P-CA-C-8827 |
| Weight | 2.5 kg |
Description
- Flame retardant tubing made from Electron Beam Cross Linked Polyolefin
- Operating temperature -75 to +135 degrees Celsius
- Resistant to common fluids, solvents and abrasion
- UV resistant
-
Pre-shrink diameter: 25.4mm
After-shrink diameter: 12.7mm
Recovered wall thickness: 0.87mm
Length: 4ft (1.2m)
-
Compliant Standards: UL224 VW1 File No. E366157, ASTM D2671
Continuous Operating Temp: -75 to +135 degrees Celsius
Shrinkage Temp: > 105 degrees Celsius
Longitudinal Shrinkage < 5%
Tensile Strength: 10.4 MPa
Breakdown Voltage: 25 kV/mm wall thickness
Elongation at Break Point: 400%
Water Absorption: 0.15% max
Voltage Rating: 600V
Heat Shock: 250 degrees for 4 hours
