ABB Switch-Disconnector OETL3150KV12/ 1SCA022290R3390
- SKU
- P-AB-A-3216
$3,500.00
Price includes GST.
Low stock: 1 left
Warehouse pickup available
- Weight
- 21.0 kg
Specifications
| Manufacturer | ABB |
|---|---|
| Product type | Electrical |
| SKU | P-AB-A-3216 |
| Weight | 21.0 kg |
Description
- Description: OETL3150KV12 switch-disconnector
- Product ID: 1SCA022290R3390
- Extended Product Type: 1SCA022290R3390
- Product Net Weight: 40 kg
- Product Net Width: 443 mm
- Product Net Height: 372 mm
- Product Net Depth: 271 mm
- Product Main Type: OETL3150
- Product Name: Switch-disconnector
- Standards: IEC
- Number of Poles: 3
- Terminal Type: Lug terminals
- Power Loss: at Rated Operating Conditions per Pole 140 W
- GL Certificate: 1SCC301046D0201
- Mounting Type: Normal
- Handle Type: None
- Order Multiple: 1 piece
- Switches Operating Mechanism: Mechanism Between the Poles
- Position of Line Terminals: Top In - Bottom Out
- Special Functions: No
- Operating Mode: Front Operated
